VICTRON 24 - 12V 100 AMP VOLTAGE REDUCER
Availability:
Call for Price & Availablity
Part No
ORI241221226
Price: Login to see price...
VICTRON 24 - 12V 100 AMP VOLTAGE REDUCER
Specifications
| Input voltage range | 18-35VDC |
| Under voltage shutdown | 15V |
| Under voltage restart | 16V |
| No load current at 24V | 85mA |
| DC output voltage | 12V +/- 3% |
| Maximum continuous output current | 100A |
| Efficiency | 96% |
| Ripple & Noise | 150mVpp |
| Operating temperature range | -40 to +70°C (full rated output up to 40°C) |
| Overload protection | Hiccup mode, recovers automatically after fault condition is removed |
| Short circuit proof | Yes |
| Protection against reverse polarity connection | With external fuse or circuit breaker (not included) |
| Material & Colour | Aluminium (blue RAL 5012) |
| Protection category | IP67 |
| DC connection | Bolts M6 |
| Cable cross section, input | n.a. |
| Cable cross section, output | n.a. |
| Weight (kg) | 2.15 kg |
| Dimensions (h x w x d in mm) | 265 x 127 x 63 |
| Safety | EN 60950 |
| Emission | EN 61000-6-3, EN 55014-1 |
| Immunity | EN 55014-2, EN 61000-6-1, EN 61000-6-2 |
| Vibration | IEC 68-2-6: 10-150 Hz / 1.0 G |
