AERPRO 9" MULTIMEDIA RECEIVER TO SUIT MAZDA 3 WITH 720P CAMERA
Brand:
Aerpro
Availability:
Call for Price & Availability
Part No
AMDMZ6
Price: Login to see price...
AERPRO 9" MULTIMEDIA RECEIVER TO SUIT MAZDA 3
The Aerpro AMDMZ6 9" Multimedia Receiver with Wireless Apple CarPlay, Android Auto and DAB+ suits Mazda 3 BK (2004-2009) non-amplified vehicles. Featuring a large 9" capacitive touchscreen display with a crisp 1024x600 resolution, this Multimedia Receiver has Apple CarPlay and Android Auto which can be used wireless or wired, built-in Bluetooth V5 for hands-free phone calls & wireless audio streaming, dual rear USB inputs, built-in DAB+ digital radio for crystal-clear sound and a wider range of stations, as well as an AM/FM radio tuner. Sound quality is superb with 50Wx4 max output, 13-band graphic EQ and time alignment capabilities, amplifiers can be added to the system via the 4V/5CH RCA preouts. Supplied as a complete Head Unit Upgrade Kit, the Aerpro AMDMZ6 includes all the parts required to complete the installation and retains important vehicle features including steering wheel controls. A universal 720P AHD rear camera is also included in this kit.
Important Information:
- Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
- Suits factory non-amplified vehicles.
- This head unit is sold as a kit which includes:
- AM905D Multimedia Receiver
- Silver Facia Kit
- Steering Wheel Control Interface Harness
- SWC Patch Lead
- 720P AHD Universal Rear Camera
Features
- Complete Head Unit Upgrade Kit: Includes all the parts required to complete the installation and retain important vehicle features for Mazda 3 (2004-2009) - Non-Amplified.
- Vehicle Feature Retention: Retains steering wheel controls.
- Large 9" Capacitive Touchscreen Display: Crisp 1024x600 resolution with smooth, responsive control for easy navigation of maps, media, and menus.
- Wireless Apple CarPlay & Android Auto: Instantly access maps, music, calls, and messages without plugging in your phone, or connect via USB for wired operation and charging.
- Built-In DAB+ Digital Radio: Enjoy crystal-clear digital sound quality and a wider range of stations, plus AM/FM tuning with RDS for all your broadcast preferences.
- Bluetooth Hands-Free Calling & Audio Streaming: Bluetooth V5 with HD Voice support, internal and external microphone options, and full phonebook and audio streaming capability.
- USB Media Playback Support: Play music, videos, and photos directly from a USB drive in popular file formats.
- 720P AHD Universal Rear Camera Included: Improve visibility and confidence when reversing, with an additional camera input available for a front or towing camera.
- High-Power Audio with Advanced Tuning: 4 x 50W Max output, 5-channel 4V RCA preouts, 13-band EQ, time alignment, and subwoofer control for clear, powerful sound.
- Multi-Colour Key Illumination: Customisable 6-colour button lighting to match your vehicle's interior.
Specifications
AMDMZ6 HEAD UNIT UPGRADE KIT SPECIFICATIONS:
- Kit Inclusions:
- AM905D Multimedia Receiver
- Silver Facia Kit
- Steering Wheel Control Interface Harness
- SWC Patch Lead
- 720P AHD Universal Rear Camera
- Vehicle Feature Retention:
- Steering Wheel Controls: Yes
- Factory Reverse Camera: N/A
- AUX Input: N/A
- USB Input: N/A
- Parking Tones: N/A
- Factory Amplifier: No
- Vehicle Menu: N/A
- Other: N/A
AM905D MULTIMEDIA RECEIVER SPECIFICATIONS:
- LCD Display:
- Size: 9"
- Resolution: 1024x600
- Touch Screen: Capacitive
- OS System: Linux
- DIN Size: Fixed Screen Style (Trapezoid)
- Power Output:
- MAX Power (4 Ohm): 4CH x 50W
- Media Playback: MP3 / MP4 / MKV / FLAC / Xvid
- Device Ports:
- USB1 (Rear): Apple CarPlay & Android Auto with Charging Function – 5V / 1.5A
- USB2 (Rear): Media with Charging Function – 5V / 1.5A
- USB MAX Capability: FAT32_32GB
- Aux Inputs / Outputs:
- Rear A/V Input (RCA Type – 3pcs): Yes
- Composite Video Output: Yes (Two)
- Reverse Camera Input: Yes (720P AHD Compatible)
- Second Camera Input: Yes (720P AHD Compatible)
- Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)
- Bluetooth:
- Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)
- Bluetooth Version: V5
- Microphone: Internal + External Microphone
- ID3 Tag/Information (Artist, Album, Song): Yes
- HFP Profile: HFP 1.6 (HD Voice)
- Tuner:
- DAB: Yes
- AM/FM (# of Presets): AM 12 / FM 18
- FM Frequency Span (MHz): 87.5–108.0MHz (0.05MHz Step)
- AM Frequency Span (KHz): 522–1710KHz (9KHz Step)
- RDS: Yes
- RCA Preamp Outputs:
- RCA Preamp Output: 4V, 5 Channel – 3 Pair (Front / Rear / Subwoofer)
- Subwoofer Level Control: Yes
- Preamp Voltage: 4V p-p
- Tone Control:
- 13-Band EQ: 32/63/125/250/500/1K/2K/4K/8K/10K/12K/14K/16K
- Loudness: Yes
- LPF – Frequencies (Sub): Yes
- Preset EQs: 6+2 Custom
- Time Alignment: Yes
- Other Features:
- Steering Wheel Control: Yes, with Aerpro SWC Adaptor
- OSD Language: English
- LED Colour (Buttons / Keys): 6-Colour Options (Red, Yellow, Green, Blue, Purple, White)
- Inclusions:
- 9" Fixed Headunit (Trapezoid)
- Mounting Hardware Screws
- Wiring Harness with ISO Connection
- AV, USB and Camera Harnesses
- DAB Antenna
- 3 Wire Learning SWC Lead
- External Microphone with Mount
- GPS Antenna with Adhesive Pad
- QR Digital Manual Leaflet
AHD Camera Specifications:
- Inclusions:
- 720P AHD Universal Rear Camera (wired)
- Mount Type: Surface Mount
- Camera Type: Rear / Reverse
- Image Sensor: Sony 225, 1/3 CMOS AHD
- Lens Angle: 150 Degree
IMPORTANT INFORMATION:
- Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
- Suits factory non-amplified vehicles.
